Full bore - RF - 150# Body and bonnet in A105 Disc, ball and plug in F6A Stem in F6A Seat in F6A Seat inserts in Devlon Seal in Viton Packing in graphite Gasket in 316+graphite Bolts and nuts in B7M/2HM With E-actuator with integrated controls and mechanical transmission type SA 07.6-B90/AM 01.1/GS 125.3 (208:1) DC1 RR Actuator: SA 07.6-B90/AM 01.1 Time/outp. speed: ± 35 sec. / 90° Duty class: S2-15 min, klasse A & B (EN 15714-2) Power supply: 3ph/400V/50Hz Wiring diagram: MSP1110KC3--F18E1 TPA00R1AB-101-000 Seating: Open=Limit, Close=Limit Self-retaining: Local=Yes, Remote=Yes IP-class: IP68 volgens EN 60529 Corrosion syst.: KS Colour: AUMA Silver grey (similar to RAL 7037) Torque setting: 31 Nm open, 31 Nm close Gearbox: GS 125.3 (208:1) DC1 RR IP-class: IP68 volgens EN 60529 Corrosion syst.: KS Colour: AUMA Silver grey (similar to RAL 7037) Output drive: A-stem nut, undrilled dmax. = 75 mm Coupling bush: coupling bush with bore and keyway according to DIN6885,1 d= 55 mm Output flange: F25-N according to ISO 5211 Max. torque: 4362 Nm Pos. indication: Mechanical
